Product Description Of MSP430F5172IRSBR

MSP430F5172IRSBR is 16-Bit Mixed-Signal Microcontrollers, Operating Frequency up to 25MHz.
MSP430F5172IRSBR microcontrollers include two 16-bit high-resolution timers, two USCIs (USCI_A0 and USCI_B0), a 32-bit hardware multiplier, a high-performance 10-bit ADC, an on-chip comparator, a 3-channel DMA, 5-V tolerant I/Os, and up to 29 I/O pins.

Specification Of MSP430F5172IRSBR

Features Of MSP430F5172IRSBR

Low Supply-Voltage Range: 3.6V Down to 1.8V
Ultra-Low Power Consumption
– Active Mode (AM): 180 µA/MHz
– Standby Mode (LPM3 WDT Mode, 3 V): 1.1µA
– Off Mode (LPM4 RAM Retention, 3 V): 0.9µA
– Shutdown Mode (LPM4.5, 3 V): 0.25µA
Wake up From Standby Mode in Less Than 5µs
16-Bit RISC Architecture, Extended Memory, 40-ns Instruction Cycle Time
Flexible Power-Management System
– Fully Integrated LDO With Programmable Regulated Core Supply Voltage
– Supply Voltage Supervision, Monitoring, and Brownout
Unified Clock System
– FLL Control Loop for Frequency Stabilization
– Low-Power Low-Frequency Internal Clock Source (VLO)
– Low-Frequency Trimmed Internal Reference Source (REFO)
– 32-kHz Crystals (XT1)
– High-Frequency Crystals up to 25 MHz (XT1)
Hardware Multiplier Supports 32-Bit Operations
3-Channel DMA
Up to Twelve 5-V-Tolerant Digital Push/Pull I/Os With up to 20-mA Drive Strength(1)
16-Bit Timer TD0 With Three Capture/Compare Registers and Support of High Resolution Mode (1) Full functionality in the 40-pin QFN package options.
16-Bit Timer TD1 With Three Capture/Compare Registers and Support of High Resolution Mode
16-Bit Timer TA0 With Three Capture/Compare Registers
Universal Serial Communication Interfaces (USCIs) (1)
– USCI_A0 Supports:
– Enhanced UART Supports Automatic BaudRate Detection
– IrDA Encoder and Decoder
– Synchronous SPI
– USCI_B0 Supports:
– I2C
– Synchronous SPI
10-Bit 200-ksps Analog-to-Digital Converter (ADC)
– Internal Reference
– Sample-and-Hold
– Autoscan Feature
– Up to 8 External Channels and 2 Internal Channels, Including Temperature Sensor(1)
Up to 16-Channel On-Chip Comparator Including an Ultra-Low-Power Mode(1)
Serial Onboard Programming, No External Programming Voltage Needed

Applications Of MSP430F5172IRSBR

Analog and Digital Sensor Systems
LED Lighting
Digital Power Supplies
Motor Controls
Remote Controls
Thermostats
