LT3008IDC Integrated Circuit Chip 20mA 45V Low Dropout Linear Regulators DFN-6

LT3008IDC Integrated Circuit Chip 20mA 45V Low Dropout Linear Regulators DFN-6​

Product Description Of LT3008IDC

LT3008IDC is micropower, low dropout voltage (LDO) linear regulators. The devices supply 20mA output current with a dropout voltage of 300mV. No-load quiescent current is 3μA. Ground pin current remains at less than 5% of output current as load increases. In shutdown, quiescent current is less than 1μA.

LT3008IDC regulators optimize stability and transient response with low ESR ceramic capacitors, requiring a minimum of only 2.2μF. The regulators do not require the addition of ESR as is common with other regulators. Internal protection circuitry includes current limiting, thermal limiting, reverse-battery protection and reverse current protection.

Specification Of LT3008IDC

Features Of LT3008IDC

Ultralow Quiescent Current: 3μA
Input Voltage Range: 2.0V to 45V
Output Current: 20mA
Dropout Voltage: 300mV
Adjustable Output (VADJ = VOUT(MIN) = 600mV)
Fixed Output Voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V
Output Tolerance: ±2% Over Load, Line and Temperature
Stable with Low ESR, Ceramic Output Capacitors (2.2μF Minimum)
Shutdown Current: <1μA
Current Limit Protection
Reverse-Battery Protection
Thermal Limit Protection
TSOT-23 and 2mm × 2mm DFN Packages

Applications Of LT3008IDC
Automotive
Low Current Battery-Powered Systems
Keep-Alive Power Supplies
Remote Monitoring
Utility Meters
Low Power Industrial Applications
