S912XET256J2VAG Microcontroller MCU 50MHz 16-Bit HCS12X Microcontroller IC LQFP-144

S912XET256J2VAG Microcontroller MCU 50MHz 16-Bit HCS12X Microcontroller IC LQFP-144​

Product Description Of S912XET256J2VAG

S912XET256J2VAG is a high-performance 16-bit automotive-grade microcontroller designed for automotive body control, in-vehicle networks and industrial control applications. Based on the enhanced S12X core, it integrates an XGATE coprocessor, large-capacity Flash memory, multiple CAN/LIN/SCI communication interfaces, a high-precision ADC and comprehensive system protection functions. Designed specifically for high-reliability, high-real-time automotive electronic control units, it delivers near-32-bit computational performance whilst retaining the efficiency, low cost and low power consumption advantages of a 16-bit MCU.

Specification Of S912XET256J2VAG

Features Of S912XET256J2VAG

Dual-core architecture, high-performance real-time processing: the main CPU and XGATE coprocessor operate in parallel, with the XGATE independently handling interrupts, communication and I/O tasks, significantly enhancing real-time response and throughput. This makes it suitable for complex in-vehicle systems with multiple buses and sensors.
High-reliability automotive-grade design: AEC-Q100 certification, ECC flash error correction, MPU protection, LVD / watchdog / clock monitoring, meeting automotive functional safety and long-term stable operation requirements.
Multi-protocol in-vehicle network support: Integrated dual CAN + dual LIN, directly supporting body domain network communication without the need for external transceiver drivers, simplifying hardware, reducing costs and enhancing EMC performance.
Large-capacity storage and efficient architecture: 256KB Flash + 16KB RAM + 4KB emulated EEPROM, meeting the storage requirements for complex firmware, calibration data and fault codes.
Extensive peripherals and I/O: 24-channel 12-bit ADC, multiple PWM/timers, and 119 GPIOs, covering all scenarios including sensor acquisition, actuator control and instrument cluster management.
Low power consumption and wide voltage range: supports multiple low-power modes (STOP/WAIT), with a wide voltage range compatible with 12V vehicle battery systems, featuring low quiescent current and fast wake-up response.
