SI8660BD-B-ISR Digital Isolator IC Chip with 5000Vrms Isolation 150Mbps Data Rate and Low Power Operation

SI8660BD-B-ISR Digital Isolators offer highly reliable, high-speed operation for demanding applications with isolation ratings up to 5kV. These digital isolators replace optocouplers in applications requiring robust operation and high levels of insulation protection, such as industrial automation and drives, motor control, and medical systems.

The SI8660BD-B-ISR provides isolation solutions for isolated AC-DC and DC-DC power supplies, solar panel microinverters, data communications systems, and hybrid electric vehicles (HEVs). These isolators deliver a data rate of 150Mbps across a temperature range of -40°C to +125ºC, with ultra-low-power operation of less than 1.6mA per channel at 1Mbps for energy-efficient system design.

• Up to 5000VRMS isolation
• UL, CSA, VDE, CQC certification
• 60-year life at rated working voltage
• High electromagnetic immunity
• Supply voltage 2.5 to 5.5V
• AEC-Q100 qualification
• Common mode transient immunity 50kV/μs
• Independent, bidirectional SDA and SCL isolation channels
• Open-drain outputs with 35mA sink current
• Supports I2C clocks up to 1.7MHz
• Unidirectional isolation channels support additional system signals
• -40 to +125°C temperature range

• AC induction motor
• Battery voltage domain
• Brushed and brushless DC motor
• DSL integrated access device with isolated FXS
• Electricity meters
• Electronic lighting ballast
• Integrated digital TV
• Industrial automation/programmable logic controller
• Metering aggregator
• Motor control
• Optical network unit
• PLC and I/O modules
